Detail Specifications

    Continue Power: 300W
Max. Output Surge: 600W
   DC Input Voltage: 12V or 24V
AC Output Voltage: 110V or 220V

           Weight (kg): 0.95 kg

• Digital microprocessor design
• Short circuit alarm and protection
• Overload alarm and protection
• Reverse polarity protection
• Intelligent over temperature alarm and shutdown
• High and low battery voltage alarm and shutdown
• Intelligent disperses heat system
• High surge capacity for starting demanding loads
• Stable output voltage and frequency
• Low no load current draw
• Advanced SMT technology
• Modified Sine Wave output

Computers, medical instruments, cash registers, TVs, DVD players, audio equipment, fax machines, limousines, buses, RVs, air-pumps, various types of light duty motors, etc.

Model		YPM-300-12	YPM-300-24
Output	Continuous output	300W
	Surge Power	600W
	Voltage	100V / 110V / 115V / 120V / 200V / 220V / 230V / 240V to be selected
	Regulation	Vrms ± 8%
	Frequency	50 Hz or 60Hz ± 1%
	Wave Form	Modified Sine Wave
Input	Voltage	12V	24V
	Low Battery	10.5V ± 0.3V Alarm 10V ± 0.3V Shutdown	21V ± 0.4V Alarm 20V ± 0.4V Shutdown
	High Battery	Over 16V alarm sounds and shutdown	Over 32V alarm sounds and shutdown
	No load current (A)	0.06 amp
	Efficiency	Over 90%
Protection	High temperature	＞60℃ alarm ＜56℃ alarm off ＞65℃ shutdown
	Short-circuit	Yes
	Overload	Yes
	Cooling Fan	No
Indicator	Audio Sound	bi—(shutdown) bi—(low battery) bi-bi—(high temperature) bi-bi-bi—(overload)
	Visual	LED Red Light  :  Inverter is ON
Mechanical	Dimensions (mm)	(137+25) x 112 x 58
	Weight
